Audio Encoding

Audio Channels

Up to 16 embedded audio channels in 8 channel pairs–4 groups with 2 pairs per group.

Audio Bitrates

• Mono: 12-288 kbps

• Stereo: 14-576 kbps

• 3.0: 16-864 kbps

• 4.0: 18-1152 kbps

• 5.0: 20-1440 kbps

• 5.1: 21-1440 kbps

• 7.1:  25-2016 kbps

Frequency Response

From 20 Hz to 17 kHz

Sampling Rate

• 48 kHz

• 16 kHz (analog only)

Audio Formats

Audio Modes

• Stereo

• Mono Left

• Mono Right

• 3.0

• 4.0

• 5.0

• 5.1

• 7.0

Note

Channel Mode 7.0 is only available when the Codec is 16-bit Pass-through.

• 7.1
