Managing Server Redundancy

You can set up a manager redundancy pool to ensure a high availability of the Manager service. The aim is to minimize operational impacts in case of an unlikely server failure.

Automatic Manager redundancy requires a Manager redundancy package. Please contact your sales contact for more details.

You need to configure:

• 2 Manager servers (one acting as a Master Manager and one acting as a Backup Manager)

• a third service (Redundancy Arbiter), hosted on a third machine that can be a virtual one

The purpose is to:

• replicate the Master Manager database onto the Backup Manager database.

• automatically detect the Master Manager failure and perform an automatic failover switch to the Backup Manager.

• give a virtual IP to point to the effective running server (Master by default) for end users and field unit connections.

Requirements:

• Master Manager, Backup Manager and Redundancy arbiter are on the same LAN.

• Make sure that a virtual IP address is dedicated to the redundancy pool.

Important

Once redundancy is configured, initial data on the Backup Manager are deleted and replaced by the Master manager database.
